Pure Sine Wave Power Inverter from China manufacturer - shenzhen easydrive electric co.,ltd.

Price:	99.0~1000.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: ED3100

Production Capacity: 5000

Delivery Date: About 7-25days

Output Type: Triple

Brand Name: EASYDRIVE

Weight: 5.50KGS

Output Voltage: 380V 3PH

Power: 5.5Kw

name: Inverter

Delivery port: Shenzhen

Means of Transport: Ocean,Air;express

Packing: In Carton

Type: Others

Output Power: >500W

Size: 270x226x179MM

Input Voltage: 380V 3PH

Protection degree: IP20

Shell material: Plastic

Origianl: Made in China

1)sell 10000pcs/month inverter
2)Top 10 inverter brand
3)30%-50% energy saving
4)1pc MOQ
5)1-3 days delivery after payment

Product characteristics :

1, open-loop vector control, V / F control method can choose to (P0.0 parameter setting)

2, V / F Curve Flexible configuration: linear V / F curve, the square of V / F curve, user-defined V / F curve.

3, stopping when the electrical parameters of self-test: In the motor perfectly still under the automatic identification of motor parameters in order to get the best control effect.

4, the external terminal multi-stage speed control, programmable multi-stage speed and pendulum frequency operation.

5, multi-frequency input channel mix setting.

6, multi-function programmable inputs, programmable relay output.

7, the standard built-in PID regulator, a simple user-friendly flow, pressure and other closed-loop control.

8, the choice of the cooling fan power up and running the work of two states.

9, switch input channels: positive, reverse order; 6 programmable switch inputs, up to 30 functions can be set.

10, standard RS485 interface to the bottom.

11. Frequency Resolution: Digital Set reach 0.01HZ; simulation settings: the highest frequency X0.1%

ED3100		Specifications
Input	Rated voltage and frequency	Single-phase 220V, three-phase 220V, three-phase 380V; 50Hz/60Hz
	Variable allowable value	Voltage: -20% +20 Voltage unbalance: <3% Frequency: ±5
Output	Rated voltage	0200V /0380V
	Frequency range	0Hz400Hz
	Overload capability	150% for 1 min, 180% for 1s, 200% instant protection
Main control function	Control mode	Space voltage vector PWM control ; Sensorless vector control (SVC)
	Frequency accuracy	Digital setting: Max frequency ×±0. 01% Analog setting: Max frequency ×±0. 2%
	Frequency resolution	Digital setting: 0.01Hz Analog setting: Max frequency ×0.1%
	Torque rise	Auto torque rise, manual torque rise 1%30.0%
	V/F curve	Three ways Linear V/F curve, square V/F curve, user self-defining V/F curve
	Acceleration/deceleration curve	Optional time unit (Min/s), the longest: 6000s (settable in the range of 0.13600s).
	DC braking	Be optional during both starting and stopping, the operating frequency: 020Hz,operating voltage level: 020%,operating time: settable within 020s
	Jogging	Jogging frequency range: 0.1Hz50.00Hz,jogging acceleration and deceleration time: 0.13600s.
	Built-in PID	It is convenient for forming closed loop control system, applicable for course control like pressure and flow, etc.
	Multi-speed operating	Realize multi-speed running by built-in PLC or control terminal.
	Weaving wobble frequency	Can get wobble frequency of adjustable central frequency
	Auto voltage adjustment	When main voltage changes, the output voltage may be kept constant by adjusting PWM output (AVR function).
	Auto energy-saving running	According to load condition, V/F curve can be optimized automatically to get the aim of energy-saving running.
	Auto current limiting	Limit in-service current automatically, so as to avoid tripping for fault caused by frequent over current.
Sensorless vector control	Torsion characteristic	150% output of torque at 1Hz, rev accuracy: 0.1%
	Motor parameters automatic read	Reading the parameters from motor when completely stop in order to achieve optimal controlling effect.
Running function	Running command passage	Setting of operating manual; setting of control terminal; setting of serial port; switching by three ways
